QAL10-3-1.5
This alloy has higher mechanical properties , and with high mechanical properties, good wear properties and corrosion resistance, easy to machining, brazing and welding performance is good, small shrinkage coefficient, non-magnetic.
MOQ : 1 MT
Length : 500-5000 MM
OD : 10-200MM
Properties
Chemical Composition
| Alloy |
Chemical Composition |
|||
| Al |
Fe |
Mn |
Cu |
|
| QAl10-3-1.5 |
8.5-10 |
2.0-4.0 |
1.0-2.0 |
Rem |
Specification
| Product |
Alloy |
shape |
Temper |
Size |
|
| OD. |
Length (mm),max. |
||||
| Extruded rod |
QAl10-3-1.5 |
round
|
R |
15-200
|
OD≤50 L1000-5000 OD＞50-70 L500-5000 OD＞120 L300～4000 |
| Drawn rod |
QAl10-3-1.5 |
Round, square , hexagonal |
Y
|
10-40
|
OD≤50 L1000-5000 OD＞50-85 L500-5000 |
Features
1) Good wear resistance
2) Excellent corrosion resistance
3) High resistance to high temperature, high pressure
4) Hot Forging performance
5) Good cutting performance
Extruded rod/bar
Drawn rod/bar
Typical Uses
Used in various industrial departments
