HPB59-1 ROD
Easy cutting brass has excellent cutting and drilling performance. It has excellent cutting performance, wear resistance and high strength.It has good mechanical properties, such as good plasticity, easy cutting, easy welding, and corrosion resistance.We maintain inventory in rounds,square ,hexagonal,and rectangle (flat) bar.
MOQ : 1MT
Length : 500～5000 MM
OD : 6-220 MM
Properties
| Alloy |
products |
shape |
Temper |
Size |
|
| OD. |
Length (mm),max. |
||||
| HPb59-1 |
Extruded bars |
round |
R |
10-220 |
Diameter(or margin)≤50 L1000～5000 Diameter(or margin)＞120 L300～4000。 |
| square , hexagonal |
10-50 |
||||
| rectangle (flat) |
10-120 |
||||
| Drawn bars |
Round, square , hexagonal |
Y2 |
6～60 |
Diameter (or margin)≤50 L1000～5000 |
|
| rectangle (flat) |
Y2 |
9～40
|
|||
Chemical Composition
| Alloy |
Chemical Composition(%) |
||||
| Cu |
Fe |
Pb |
Zn |
Other Elements |
|
| Hpb59-1 |
57.0-60.0 |
0.5 |
0.8-1.9 |
Rem. |
1.0 |
| C37700 |
58.0-61.0 |
0.3 |
1.5-2.5 |
Rem. |
0.8 |
| C36000 |
60.0-63.0 |
0.35 |
2.5-3.7 |
Rem. |
0.85 |
| Temper |
shape |
Diameter (or margin) |
Tensile Strength Rm/ (N/mm2) |
Elongation A/ % min |
| Y2 |
Round, square , hexagonal |
3~20 |
≥420 |
12 |
| 20~40 |
≥390 |
14 |
||
| 40~80 |
≥370 |
19 |
||
| rectangle (flat) |
5~20 |
≥390 |
12 |
|
| 20~80 |
≥375 |
18 |
||
| R |
- |
≤160 |
≥340 |
17 |
Features
1) Good wear resistance
2) Excellent corrosion resistance
3) High intensity
4) Hot Forging performance
5) Good cutting performance
6) Self-lubricating performance
Drawn rod/bar
Extruded rod/bar
Typical Uses
Lead brass has a very high cutting performance, chip fragile, smooth surface, suitable for automatic high-speed lathe processing parts.
