H65 BRASS STRIP
It has good shape and high strength, good cutting performance and welding performance. Widely used in cold and deep pieces.
MOQ : 1MT
Thickness : ＞0.15-3.0 MM
Width : ≤1000 MM
Properties
| Alloy |
product |
Temper |
size（mm） |
|
| Thickness |
width |
|||
| H65 |
strip |
TY、T、Y、Y2、 Y4、M |
>0.15-0.5 |
≤600 |
| >0.5-3.0 |
≤1000 |
|||
chemical Composition
| Alloy |
Chemical Composition％ |
|||
| Cu |
Pb |
Fe |
Zn |
|
| H65 |
63.5~68.0 |
≤0. 1 |
≤0.03 |
Rem |
Mechanical Properties
| Alloy |
Temper |
Rm/OViran2) Tensile Strength |
au.3/% Elongtion |
Hardness(HR) |
|
H65 |
M |
≥290 |
≥40 |
≤90 |
| Y4 |
235-410 |
≥35 |
85-115 |
|
| Y2 |
355-460 |
≥25 |
100-130 |
|
| Y |
410-540 |
≥13 |
120-160 |
|
| T |
520-620 |
≥4 |
150-190 |
|
| TY |
≥570 |
- |
≥180 |
Features
1) Good elongation
2) Extruded well
3) Processed well
4) Electroplated well
Typical Uses
Key / lock cylinder, Ornaments, Terminals,Radiators for cars,Components of camera, Handicraft articles, Thermos bottles, Electrical equipment, Accessories ,Ammunitions,etc.
