C10200 ROD
copper rods can be used in a wide range of applications such as forged fittings for the sanitary industry, for lock barrels and for machined parts in mechanical engineering.
MOQ : 1 MT
Length : 500-5000 MM
OD : 16-300 MM
Properties
chemical Composition
| Alloy |
Chemical Composition (％) |
||||||||||||
|
C10200 |
Cu+Ag |
P |
Ag |
Bi |
Sb |
As |
Fe |
Ni |
Pb |
Sn |
S |
Zn |
o |
| ≥99.97 |
0.002 |
— |
0.001 |
0.002 |
0.002 |
0.004 |
0.002 |
0.003 |
0.002 |
0.004 |
0.003 |
0.002 |
|
| Product |
Alloy |
shape |
Temper |
SIZE |
|
| OD. |
Length (mm) |
||||
| Extruded rod |
C10200 |
Round |
R |
16-300 |
OD≤50 L1000-5000 OD:50-75 L500-5000 OD＞75-120 L500-4000 OD＞120 L300-4000 |
| square , hexagonal |
16-120 |
||||
| Drawn rod |
C10200 |
Round, |
M, Y
|
6-80 |
OD≤50 L1000～500 OD＞50-80 L500～5000 |
| square , hexagonal |
8-60 |
||||
Features
1) Good wear resistance
2) Excellent corrosion resistance
3) High resistance to high temperature, high pressure
4) Good cutting performance
Extruded rod/bar
Drawn rod/bar
Typical Uses
Electrical conductivity and thermal conductivity of copper is second only to silver, widely used in the production of conductive, thermal conductivity apparatus.Copper in the atmosphere, water, and some non oxidizing acid have good corrosion resistance, used in the chemical industry.
