C26000 BRASS PLATE
It has good shape and high strength, good cutting performance and welding performance. Widely used in cold and deep pieces.
MOQ : 1MT
Length : ≤6000 MM
Thickness : 0.3-120 MM
Width : ≤3000MM
Properties
| Alloy |
process |
Size（mm） |
||
| Thickness |
Width |
Length |
||
| C26000 |
Hot rolling |
4-8 |
600-2000 |
≤4000 |
| 8-60 |
600-3000 |
≤6000 |
||
| >60-120 |
600-2000 |
≤4000 |
||
| Cold rolling |
0.3-0.5 |
≤600 |
≤2000 |
|
| >0.5-3.0 |
≤1000 |
≤3000 |
||
| >3.0-10 |
≤3000 |
≤6000 |
||
chemical Composition
| Alloy |
Chemical Composition％ |
|||
| Cu |
Pb |
Fe |
Zn |
|
| C26000 |
68.5-71.5 |
≤0.07 |
≤0.05 |
Rem |
Mechanical Properties
| Alloy |
Temper |
Tensile Strength |
Elongation |
Hardness(HR) |
| C26000 |
O |
≥290 |
≥35 |
<95 |
| H/4 |
350~470 |
≥20 |
90 ~130 |
|
| H/2 |
410~630 |
≥10 |
125~165 |
|
| H |
≥585 |
≥2.5 |
≥155 |
Features
1) Good elongation
2) Extruded well
3) Processed well
4) Electroplated well
Thick plate/sheet
Thin plate/sheet
Typical Uses
Key / lock cylinder,Ornaments,Terminals, Radiators for cars, Components of camera,Handicraft articles, Thermos bottles,Electrical equipment, Accessories
Please contact one of our knowledgeable sales staff to help you with your Copper needs.
Request a Quote
* Required Fieds|We will reply you in 24 hours
You can contact us by E-mail or other ways.We will respond You in 24hours.
